B-1416 Needle roller bearings 3261519416
The B-1416 needle roller bearing (also often written as B1416 or B-1416) is a stamped outer ring full complement needle roller bearing, commonly found in the imperial series. Its main parameters are as follows:
Basic Dimensions
Inner Diameter (d): 22.22 mm
Outer Diameter (D): 28.58 mm (some sources record it as 28.575 mm)
Thickness (B): 25.4 mm
Other Key Parameters
Weight: Approximately 0.034 kg (34 grams)
Material: Usually high carbon chromium bearing steel (GCr15), fully hardened
Precision Grade: Generally... P0 (General Purpose)
Type: Stamped outer ring full complement needle roller bearing (no cage, full complement needle rollers to improve load capacity)
Applications: Suitable for applications requiring high radial loads and certain impact loads.
Commonly found in: machine tools, metallurgical machinery, textile machinery, printing machinery, etc.
Compact structure, high rotational accuracy, suitable for space-constrained applications.
Notes: B-1416 and BK1416 (inner diameter 14mm) have different dimensions and are not interchangeable. BK1416 belongs to the metric series (14กม20กม16), while B-1416 belongs to the imperial series (22.22กม28.58กม25.4). To confirm the specific model, it is recommended to check the complete model designation on the bearing or refer to the supplier's technical drawings.
