7307AC/P6 Angular Contact Ball Bearings 431513416
7307AC/P6 is an angular contact ball bearing with the following specifications:
Basic Dimensions
Inner Diameter (d): 35 mm
Outer Diameter (D): 80 mm
Width (B): 21 mm
Load and Speed Performance
Rated Dynamic Load (Cr): 35.4 kN
Rated Static Load (Cor): 22.0 kN
Grease-lubricated Limiting Speed: 10,000 r/min
Oil-lubricated Limiting Speed: 13,000 r/min
Other Information
Weight: Approx. 0.475 kg
Precision Class: P6 (High precision class conforming to ISO standards, equivalent to the old standard ABEC-3 or JIS P6)
Contact Angle: AC indicates a contact angle of 25กใ (standard angular contact ball bearing designation)
